GGH Piper Series - Beveled- Top or Bottom Pivot with Attached U-Clamp Hinge

The GGH Piper Series Beveled Top or Bottom Pivot with Attached U-Clamp Hinge is a premium solution for frameless shower door installations. Designed for 3/8" (10 mm) and 5/16" (8 mm) thick tempered glass, this hinge offers a modern alternative to traditional horizontal metal header systems, providing a clean and minimalistic appearance. Its top and bottom mount design allows more glass to be visible, reducing the number of cut-outs required compared to standard side-mount glass-to-glass hinges.

Key Features:

• Materials: Solid brass with stainless steel pins and spring for durability and long-lasting performance.
• Glass Compatibility: Suitable for 3/8" (10 mm) and 5/16" (8 mm) tempered glass.
• Design: Top or bottom mount provides an elegant solution for frameless shower doors, allowing more glass visibility and reducing the number of cut-outs needed.
• Self-Centering: The hinge automatically centers when within 15º of the closed position, ensuring smooth and secure door operation.
• Installation: Simple and hassle-free installation with standard tools.

Finishes Available:

• Chrome
• Brushed Nickel
• Matte Black
• Satin Brass

Specifications:

• Glass Thickness: 5/16" (8 mm) to 3/8" (10 mm) tempered safety glass.
• Hinge Swings: Full rotation.
• Installation Requirements: Easy installation with standard tools.
• Warranty: 5 years.

For more information or to place an order, please contact us at products@ggshardware.com.
