Standoff System

Arc Series (4-way Adjustable) - Engineered

1-1/2″ (38 mm) dia × 1-1/4″ (32 mm) base height – SS316 – Round
1-1/2″ (38 mm) dia × 1-1/2″ (38 mm) base height – SS316 – Round
2″ (50 mm) dia × 1-1/4″ (32 mm) base height – SS316 – Round
2″ (50 mm) dia × 1-1/2″ (38 mm) base height – SS316 – Round
2″ (50 mm) dia × 2″ (50 mm) base height – SS316 – Round
1-1/2″ × 1-1/2″ (38 mm × 38 mm) base height – SS316 – Square
2″ × 2″ (50 mm × 50 mm) base height – SS316 – Square

Optional Items

Fasteners for Arc Series

Countersunk Anchor Bolts – M10 × 84 mm
Countersunk Wood Screw – ST10 × 100 mm
Countersunk Cap Screw – 3/8"-16 × 1-1/2" Long

Round Standoffs (38 mm / 1-1/2″ Diameter)

1/4″ (6 mm) height – stainless steel
1/2″ (13 mm) height – stainless steel
3/4″ (19 mm) height – stainless steel
1″ (25 mm) height – stainless steel
1-1/4″ (32 mm) height – stainless steel
1-1/2″ (38 mm) height – stainless steel
2″ (50 mm) height – stainless steel

Learn More

Hanger Bolts (3/8") for Solid standoffs

Hanger Bolt for Solid Standoff – 3/8" × 2-1/2"
Hanger Bolt for Solid Standoff – 3/8" × 3"
Hanger Bolt for Solid Standoff – 3/8" × 3-1/2"
Hanger Bolt for Solid Standoff – 3/8" × 4"
Hanger Bolt for Solid Standoff – 3/8" × 4-1/2"
Hanger Bolt for Solid Standoff – 3/8" × 5"
Hanger Bolt for Solid Standoff – 3/8" × 6-1/2" (3/8-16 UNC)

Round Standoffs (50 mm / 2″ Diameter) - Engineered

1/4″ (6 mm) height – stainless steel
1/2″ (13 mm) height – stainless steel
3/4″ (19 mm) height – stainless steel
1″ (25 mm) height – stainless steel
1-1/4″ (32 mm) height – stainless steel
1-1/2″ (38 mm) height – stainless steel
2″ (50 mm) height – stainless steel
2″ (50 mm) height – stainless steel HD Series (1/2″–13 Thread)

Learn More

Threaded Rods

Standoff Threaded Rod – 3/8" × 6" – SS316 (3/8-16 UNC)
Standoff Threaded Rod – 1/2" × 6-1/4" – SS316 (3/8-16 UNC) (HD Standoff)

Square Standoffs (50 mm / 2″)

1-1/4″ (32 mm) height – stainless steel
1-1/2″ (38 mm) height – stainless steel

Learn More

Gaskets

Standoff Gasket – 1-1/2" – 1 & 2 mm Thick
Standoff Gasket – 2" – 1 & 2 mm Thick

Round Standoff Caps

1-1/2″ (38 mm) diameter – stainless steel
2″ (50 mm) diameter – stainless steelStandoff Gasket – 1-1/2" – 1 & 2 mm Thick
Standoff Gasket – 2" – 1 & 2 mm Thick

Learn More

Tools

Driver for 3/8" Standoff Hanger Bolts
Wrench for 1-1/2" & 2" Standoffs
T-Wrench for Arc Series (10 mm)
Standoff Tool Kit – 1-1/2" & 2" Diameter
